Kenwood 2-Din Monitor Receiver with Bluetooth DDX395
Authorized Dealer Price Match Guarantee
Price Match Guarantee
Kawartha TV & Stereo offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.

Availability
Call for availability

Literature

6.2 inch Wide VGA Color LCD Display with LED Backlight
Clear Resistive Panel
Touch Panel Control , Variable Key Illumination
Bluetooth Built-in (Hands-Free Profile / Audio Profile(A2DP) (AAC)/ SPP)
Android Rapid Charge
RCA Video Input for Rear View Camera(Parking Guide Line)
Dual Phone Connection
Wireless Music Browsing

iDatalink Maestro RR

When an Automotive Data Solutions iDatalink Maestro RR is connected to a compatible KENWOOD receiver, it provides a seamless interface with factory infotainment features such as Satellite Radio, USB Media Player, Bluetooth hands-free and music streaming. Vehicle information such as HVAC, performance information, and TPMS can also be displayed.

Clear Resistive Touch Panel

An advanced display panel with high contrast ratio, provides a brighter and clearer visual experience with vivid easy to read text.

Viewing Angle

Electronic angle settings adjust the display for best off axis viewing.

Parking Guide Lines

Parking guide lines appear on any standard backup camera image, making parking safer and easier.

Android Music Playback (AOA2)

Simply install the Kenwood Music Play application onto your Android™ smartphone, connect it to your KENWOOD receiver via USB, and control your music directly from the car monitor receiver.

Android Rapid Charge

Rapidly charge your compatible Android smartphone with the USB port, up to a maximum of 1.5A.

Dual Phone Connection

Allows two phones to be connected for hands-free operation at any time. Easily switch between both phones with the touch of a button. Answering, calling or searching your phonebook on your phone is made simple through an intuitive GUI.

Music Mix

Up to 5 Bluetooth® devices can be connected to the head unit at the same time, and you can enjoy audio streaming just by switching the devices with your friends or family.

Remote App

A smartphone application can control most basic functions of the receiver over the Bluetooth connection of the paired phone (iPhone or Android).

Wireless Music Browsing (AVRCP 1.5)

Search and select songs from your music collection through a Bluetooth® connection.

13 Band EQ

13-Bands of equalization offer detailed audio tuning to match your taste and listening environment.

Drive EQ

Boosts specific frequencies in the audio signal to overcome the negative impact of road noise.

General Features

  • 6.2 inch Wide VGA Color LCD Display with LED Backlight
  • Clear Resistive Panel
  • Touch Panel Control
  • Variable Key Illumination
  • Top Menu and Background Customize
  • Multi-Language Menu & Tag (22 Languages (English, Spanish, French and others)

Audio/Video Features

  • Maximum Output Power : 50W x 4 (MOSFET Power IC)
  • 3 Preouts (5V)
  • 1 AV Output (V:RCA)
  • 1 RCA Video Input for Rear View Camera
  • Parking Guide Line
  • 13 Band Graphic Equalizer
  • Time Alignment
  • System E's (Built-in HPF & LPF)
  • Loudness
  • Installer & Backup Memory (Store & Backup Audio/Video Settings)

DVD/CD Features

  • DVD Video/±R/RW Playback, MPEG 1/2 Video Playback
  • VCD Compatible, MP3 / WMA / WAV / CD-R / -RW Playback
  • CD Text Ready, Repeat / Random Play
  • 24 Bit D/A Converter

Tuner Features

  • Sirius XM Ready
  • FM / AM 20 Station Presets (FM x 15, AM x 5)
  • RBDS with Radio Text Plus
  • AME (Automatic Memory Entry), Up/Down Seek Tuning

USB Features

  • USB Interface x 1 (Rear)
  • MP3 / WMA / AAC / WAV / FLAC Playback, MPEG 1/2 Video / JPEG Playback
  • iPhone/iPod USB Direct Connection with Optional Cable *1
  • iPhone App Mode
  • Pandora / iHeart Radio / Spotify App Ready (iPhone App)
  • Android Music Play Back
  • Android Rapid Charge

External Media Control Features

  • Built-in Bluetooth
  • (Hands-Free Profile / Audio Profile (A2DP) (AAC) / SPP)
  • Bluetooth Auto Pairing for iPhone, Android
  • Voice Control by Cell Phone
  • Dual Phone Connection
  • Wireless Music Browsing
  • Pandora / iHeart Radio/ Spotify App Ready (Android and iPhone App) via Bluetooth
  • Remote App
  • Music Mix
  • OEM Remote Control Interface
  • iDataLink
FM
S/N (dB)68 dB(MONO)
Frequency response (±3.0 dB)30 Hz - 15 kHz
S/N:50dB1.58 μV / 75 Ohms
Quieting sensitivity15.2 dBf
S/N:30dB0.63 μV / 75 Ohms
Usable sensitivity7.2 dBf
(Frequency step)(200 kHz)
Frequency Range87.9 MHz - 107.9 MHz
Bluetooth Section
ProfileHFP(Hands Free Profile) 1.6A2DP(Advanced Audio Distribution Profile) 1.3AVRCP(Audio/Video Remote Control Profile) 1.5GAP(Generic Access Profile)PBAP(Phonebook Access Profile) 1.2SDP(Service Discovery Profile)SPP(Serial Port Profile) 1.2
Audio CodecSBC/AAC
Maximum Communication rangeLine of sight approx.10m (32.8ft)
Output Power+4dBm (MAX),0dBm (AVE) Power Class 2
Frequency2.402 - 2.480 GHz
TechnologyBluetooth V3.0
USB I/F Section
Video DecoderMPEG1/MPEG2/JPEG
Audio DecoderMP3/WMA/AAC(.m4a/.aac)/WAV/FLAC
D/A Converter24bit
Maximum Power Supply CurrentDC5V(DC logo)=1.5A
File SystemFAT 16/32
Compatible DevicesMass storage class
USB StandardUSB2.0 Full Speed / High Speed
DVD Section
Quantifying bit number16/20/24bit
Sampling frequency44.1kHz/48kHz96kHz
DISC FormatDVD-Video/VIDEO-CD/CD-DA
Dynamic range99dB(DVD-Video 96k)
Signal to Noise ratio99dB(DVD-Video 96k)
Total harmonic distortion 1kHz0.010%
44.1k Sampling20 - 20,000 Hz
48k Sampling20 - 22,000 Hz
96k Sampling20 - 22,000 Hz
Wow & FlutterBelow Measurable Limit
Video DecoderMPEG1/MPEG2/JPEG
Audio DecoderLinear PCMDolby digitalMP3/WMA/AAC(.m4a)/WAV
D/A Converter24Bit
Monitor Section
Back lightingLED
Pixel arrangementRGB striped arrangement
Effective pixels99.99%
 800H x 480V x RGB
Number of pixels1,152,000
Drive systemTFT active matrix system
Display systemTransparent TN LCD panel
W x H137.5mm x 77.2 mm , 5-7/16 x 3-1/16
Picture size6.2 inches(diagonal) wide
General
Main unit2.0 kg / 4.4 lbs(Trimplate and sleeve : included)
Operational temperature range-10°C to +60°C
Installation Dimensions WxHxD182mm x 111mm x 162mm7-3/16 x 4-3/8 x 6-3/8 inch
Maximum Current consumption10A
Operating voltage14.4V(10.5V to 16V)
Audio
Subwoofer Level-50 to +10dB
Gain-8 to 0dB
2Way: Front / Rear /Subwoofer Delay0 - 20.0ft (0.07ft Step)
Gain-8/-7/-6/-5/-4/-3/-2/-1/0 [dB]
PhaseNormal/Reverse
Slope-6/-12/-18/-24 [dB/Oct.]
Frequency(Hz)30/40/50/60/70/80/90/100/120/150/180/220/250/Through
Gain-8/-7/-6/-5/-4/-3/-2/-1/0 [dB]
Slope-6/-12/-18/-24 [dB/Oct.]
Frequency(Hz)Through/30/40/50/60/70/80/90/100/120/150/180/220/250
Gain-8/-7/-6/-5/-4/-3/-2/-1/0 [dB]
Slope-6/-12/-18/-24 [dB/Oct.]
Frequency(Hz)Through/30/40/50/60/70/80/90/100/120/150/180/220/250
Gain-8/-7/-6/-5/-4/-3/-2/-1/0 [dB]
Frequency(Hz)1k/1.6k/2.5k/4k/5k/6.3k/8k/10k/12.5k
2Way X'Over
Q factor1.35/1.5/2.0
Gain-9/-8/-7/-6/-5/-4/-3/-2/-1/0/1/2/3/4/5/6/7/8/9 [dB]
Frequency(Hz)62.5/100/160/250/400/630/1k/1.6k/2.5k/4k/6.3k/10k/16k
BAND13Band
Speaker Impedance(Ω)4-8 Ohms
Preout Impedance(Ω)=< 600 Ohms
Preout level(V)5V / 10kOhms
Full Bandwidth Power (Front&Rear)22Wx4(at less than 1%THD)
Maximum Power (Front&Rear)50Wx4
Video
Video Output level (RCA jacks)1Vp-p / 75Ohms
Video Input level (RCA jacks)1Vp-p / 75Ohms
External audio max input level (mini jack)2V / 25kOhms
External video input level (mini jack)1Vp-p / 75Ohms
Color system of external video inputNTSC/PAL
AM
Usable sensitivity29 dBμ
(Frequency step)(10 kHz)
Frequency Range530 kHz - 1700 kHz
FM
SelectivityOver 80 dB(±400 kHz)
Stereo separation40 dB(1 kHz)
