Kenwood Compact Bluetooth 4 Channel Digital Amplifier KACM1824BT

Authorized Dealer Price Match Guarantee
Price Match Guarantee
Kawartha TV & Stereo offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.
Free Shipping
Our Price $399.00 CAD

Or as low as $70.02/month over 6 months. Apply Now


Availability
Out of stock online. Call for availability

General Features

Signal to Noise Ratio: 90 dB
RMS POWER Output 4Ω: 45W x 4
RMS POWER Output 2Ω: 45W x 4
RMS POWER Output Bridged: 90W x 2
Dimensions(WxHxD): 5-11/16" x 1-3/4" x 3-7/8"
Singal Sensing Turn-on
Conformal Coating *1

BUILT-IN BLUETOOTH

With today’s smartphones hosting a wide variety of listening choices such as stored music, internet radio, podcasts, etc., it is no wonder that customers want to use this as their primary listening source. Bluetooth offers the easiest and most popular connection, KAC-M1824BT is not only your standalone Bluetooth gateway but if used with an in-dash receiver, it will double the power of a typical CD receiver with it’s built-in 45Watts x 4 of amplification. A water resistant controller can be used to adjust volume and change tracks.

MULTI-APPLICATION

Many of today’s powersports have very limited space to work in and tend to be a harsh environment for electronics because of the exposure to outdoor environments. KENWOOD’s compact performance amplifiers are small in size so they fit even the most limited installation areas. The amplifiers also use a conformal coated main PCB (printed circuit boards) which offer extra layers of protection to help prevent moisture or damp air from damaging the product.

Specifications
Signal to Noise Ratio90dB (Reference: Rated Power into 4Ohms at 14.4V)
Maximum Power Output
MAX POWER400W
CEA-2006 Primary Ratings
Signal-to-Noise Ratio74dBA (Reference: 1Watt into 4Ohms)
Power Output45Watts RMS x 4 at 4 Ohms and ≤1%THD+N
Amplifier Type
Amplifier TypeClass D
Title
TitleCompact Bluetooth 4 Channel Digital Amplifier
Others
Othersapt-X AAC
Key Features
Key FeaturesCEA-2006 Compliant Class D 2 Ohms Load Capability Speaker Level Input Signal Sensing Turn-on Power MOS-FET Switching Power Supply Extruded Aluminum Heat Sink Design Line Output Terminals for Extension BLUETOOTH
General
Operating Voltage14.4V(11-16V allowable)
Weight  (kg)-
Dimensions(WxHxD)'5-11/16 X '1-3/4 X '3-7/8 inch
Terminals
Line InRCA (Ni)
Line OutRCA (Ni)
Speaker OutputMOLEX Connector with 1500mm Wire
Battery & GroundMOLEX Connector with 1500mm Wire
Specifications
Speaker Impedance
Input Impedance10k ohm
Frequency Response20Hz-20kHz (+0dB, -1dB)
