Kenwood Pocket-Sized UHF FM Portable Radio - PKT23LFP
Authorized Dealer Price Match Guarantee
Price Match Guarantee
Kawartha TV & Stereo offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.
Our Price $249.00 CAD
Sale Ends : June 05, 2021

Or as low as $43.70/month over 6 months. Apply Now


Availability
Call for availability

Literature

A Powerful Business Radio in the Palm of Your Hand
At only 3.9oz, Kenwood’s PKT-23 UHF two-way radio provides 1.5 watt transmit power, 16 channels, and up to 15 hours of operation. This small but powerful radio is simple to operate and durable, meeting or exceeding MIL-Spec standards 810 C/D/E/F/G (11 items) and IP54 (dust/water intrusion). Connect to the standard micro USB port to charge or use included charging cup, and plug Kenwood headphones into the 3.5mm audio jack for hands free operation. Versatile, strong, and small - the PKT-23 is built business tough.

GENERAL FEATURES

  • 1.5 Watts Transmit Power
  • 16 Channels
  • 39-QT/168-DQT Coded Squelch
  • Super Lock (Manager Key Lock)
  • Scan Function
  • 2 PF Keys
  • Enhanced Kenwood Audio
  • Micro USB Port
  • VOX Ready
  • Voice Announcement
  • Bell Tone Alert
  • LED Battery Status Indicator
  • IP54 & MIL-STD 810 C/D/E/F/G 11 items
  • Battery Saver
  • Time Out Timer
  • Monitor
  • Wireless Clone
  • 2-year Warranty

ACCESSORIES INCLUDED

  • KNB-71L - 1,430mAh Li-Ion
  • KSC-44 - 3-Hour Fast Charger
  • KBH-20 - Belt Clip
  • Owner's Manual
General
Frequency Range 451-470 MHz
BRS Preset 99 Channels
Number of Channels 16
Channel Spacing (FCC Narrow Compliant) 12.5 kHz
Channel Step 5, 6.25 kHz
Operating Voltage 3.8V DC±10%
Battery Life (5-5-90 duty cycle) with KNB-71L (1,430mAh) Approx. 11 hours (Battery saver off), Approx. 15 hours (Battery saver on)
Operating Temperature Range* -14°F ~ +140°F (-10°C ~ +60°C)
Frequency Stability ±2.5ppm (-14°F ~ +140°F)
Antenna Impedance 50 Ω
Dimensions (W x H x D), Projections not Included Radio with KNB-71L 1.8 x 3.3 x 0.8 in. (46.0 x 85.0 x 21.0 mm)
Weight (net) Radio with KNB-71L 3.9 oz. (110 g )
FCC ID ALH460300
FCC Compliance Part 90
RECEIVER (Measurements made per TIA/EIA-603)
Sensitivity (12dB SINAD) Narrow 0.22 μV
Selectivity Narrow 60 dB
Intermodulation Distortion Narrow 50 dB
Audio Output 300 mW with less than 5% distortion
TRANSMITTER (Measurements made per TIA/EIA-603)
RF Output Power High 1.5 W (ERP)
RF Output Power Low 0.5 W (ERP)
Spurious Response 55 dB
Modulation Narrow 11KØF3E
FM HUM & Noise Narrow 50 dB
Audio Distortion Less than 5%
