Sangean FM / AM Analog Wooden Cabinet Receiver - WR-11 (Wnt)
Literature
- FM / AM Analog Radio
- Tuning and Band Indicator
- Soft and Precise Tuning
- Deep Bass Compensation
- 3 Inches 6.5 Watts Full Range Speaker with Enlarged Magnet
- Auxiliary Input for Additional Audio Sources Like MP3 Player or iPod / iPhone
- I/O Jacks: AC-In, DC-In, Aux-In, REC Out, Headphone and FM F Type Antenna Terminal
TUNING | |
---|---|
Type | Analogue |
Rotary Tuning | V |
Display | |
LCD / VFD / Dial Scale | Dial Scale |
Back Light | V |
Tuner | |
FM - Frequency (MHz) | 87.5 - 108 |
AM / MW - Frequency (kHz) | 520 - 1710 |
MEDIA | |
Aux - in | V |
OUTPUT DEVICES | |
Speaker - Size ( mm / inch ) | 3 inches |
Speaker - Impedance | 8 ohms |
OUTPUT POWER (TYPICAL) | |
AC / DC / AC to AC in (Speaker) | 6.5W (AC / DC) |
Earphones | 5 + 5 mW (monaural) |
POWER SUPPLY | |
AC - USA | 120V 60 Hz |
AC - EUR | 230V 50 Hz |
DC in | 12V / 1A |
I/O SOCKET | |
DC in | V |
AC in | V |
Earphones | V |
Line - out | REC OUT |
Ext.Antenna | AM (option) / FM |
Aux - in | V |
Accessories | |
AC Cord | V |
Dimensions | |
Width (mm/inch) | 240 / 9.45 |
Height (mm/inch) | 119 / 4.69 |
Depth (mm/inch) | 168 / 6.61 |
Weight (g & lb. oz) | 2283 / 5lb. 0.5oz |
PARTICULAR PERFORMANCE | |
1 | * Deep Bass Compensation |
