Meet WiiM Bar
Display-first Dolby Atmos. Expandable to 5.1.2.
Elevate your living room with audiophile-grade 3.0.2 Dolby Atmos® and DTS:X spatial audio. Manage playback, adjust EQ, and view stunning album art directly from a vibrant 2.1” touchscreen. Ready for more? Wirelessly pair with compatible WiiM devices to seamlessly expand this perfect foundation into your ultimate 5.1.2 home theater.
One Bar for Every Way You Listen
Movie night. Morning playlists. Game day. Late-night TV. WiiM Bar fits every moment.
Start a movie through HDMI eARC and feel sound rise above the screen. Switch to music and see album art glow from the soundbar. Group with other WiiM devices for synchronized whole-home listening, or build out your living room with wireless surrounds and subwoofer support when you’re ready.
Movie Night
Dolby Atmos® and DTS:X playback bring cinematic height and immersion to your living room.
Music at a Glance
Album art, track info, playback, EQ, and presets appear right on the 2.1" touch display.
Game Day Energy
A wider soundstage and expandable surround setup help bring action into the room.
Late-Night Calm
Night Mode helps manage loud effects while keeping dialogue easier to hear.
Whole-Home Flow
Group WiiM Bar with compatible WiiM devices for synchronized multi-room music.
Control Without Friction
WiiM Bar gives you multiple ways to control your listening experience. Use the round touch display for quick playback, source selection, EQ, and Smart Presets. Open the WiiM Home App for streaming, grouping, routines, and deeper sound customization. Use Alexa, Google Assistant, or the included Voice Remote for easy everyday control.
Your music.Your way.
Total freedom for your listening experience. Stream natively via Spotify and Tidal Connect, or dive into the WiiM Home App to personalize your sound, sync multi-room audio, and browse all your services in one elegant place.
Take full control with the WiiM Bar Voice Remote
WiiM Bar Voice Remote crafted with a sleek body, rechargeable battery, and intuitive Push-to-Talk Alexa—plus smart presets and dedicated playback buttons for a seamless, intuitive experience.
Voice Control
Enjoy hands-free listening using an external Alexa or Google Home device.
Sound That Adapts to Real Rooms and Real Life
RoomFit™ auto-correction helps tailor playback to your room layout and speaker placement. Clear Voice and AI Dialog Enhancement help bring speech forward during busy scenes, while Night Mode helps reduce dramatic volume swings for lower-volume listening.
AI RoomFit™
One tap in the WiiM Home App analyzes your room using the phone's mics, then optimizes response for balanced, fatigue‑free sound—no trial‑and‑error or extra gear.
Night Mode
Night Mode Big sound, low volume. Enjoy clear dialogue and controlled dynamics for late-night viewing.
Voice Mode
Voice Mode Never miss a line. Dialogue stays crisp, focused, and easy to follow.
Movie Mode
Movie Mode Feel the scene. Expand the soundstage with cinematic impact and immersive height effects.
Music Mode
Hear more in every track. Enjoy balanced, detailed sound with a wider, more natural stage.
Built for Cinema. Tuned for Music.
An 8-driver acoustic system with 4 passive radiators, top-firing height channels, and 135W system power.
Behind the sleek form is a serious acoustic system: three front mid-woofers, three front tweeters, two top full-range height drivers, and four passive radiators. Together, they support a wide soundstage, clear vocals, height effects, and stronger bass performance from a single soundbar.
3x
Front Mid-Woofers
Body, warmth, and presence
3i
Front Tweeters
Clarity for vocals and texture
2e
Top-Firing Channels
Designed for Atmos height effects
135W
Total System Power
Built for room-filling sound
Built for Modern Home Theater
Connect through HDMI eARC and enjoy support for LPCM, Dolby Atmos/TrueHD/DD+, AC3, DTS, and DTS:X. Stream over Wi‑Fi 6E or Ethernet, connect through Bluetooth 5.4, or use optical, line-in, USB Audio In/Out, and USB Host for flexible playback.
Streaming EcosystemThe Freedom of WiiM Streaming
Stream from the WiiM Home App or connect through Google Cast Audio, Spotify Connect, TIDAL Connect, Qobuz Connect, Amazon Music Cast, DLNA/UPnP, Qplay 3.0, LMS, and Roon.
Expandable WiiM Home Theater
Start with the bar. Build the theater.
Experience cinematic 3.0.2 Dolby Atmos® and DTS:X® right out of the box. When you're ready, wirelessly add compatible WiiM surrounds and a subwoofer to build a fully immersive 5.1.2 theater at your own pace—no messy cables required.
Step 01
3.0.2 Soundbar
Immerse yourself in cinematic Dolby Atmos® and DTS:X® sound from a single, elegant soundbar.
Step 02
Wireless Surround Expansion
Place compatible WiiM speakers behind your sofa to pull the action off the screen and bring the scene right around you.
Step 03
Up to 5.1.2 System
Add subwoofer support to deliver deep, chest-thumping low-end energy for your movies, games, and music.
A New Centerpiece for the WiiM Ecosystem
Designed for movies, music, and whole-home audio—coming Q3 2026.
WiiM Bar brings the simplicity, flexibility, and high-performance streaming experience of WiiM into the living room. It was previewed as WiiM’s first soundbar at High End Vienna 2026 and is designed to anchor TV audio, music streaming, wireless surround expansion, and multi-room listening in one system.
WHAT'S IN THE BOX
- WiiM Bar
- WiiM Bar Remote
- User Guide
- Power Cable
- HDMI Cable
- Optical Cable
- Wall Brackets
| Overview | |
|---|---|
| Product name | WiiM Bar |
| Model name | WiiM Bar |
| Model number | BAR001 |
| Product type | Display-first smart soundbar |
| Tagline | See the Sound. Build the Theater. |
| Channel layout | 3.0.2 |
| Expandable home theater | Expandable to 5.1.2 with compatible WiiM surround and subwoofer devices |
| Primary use cases | TV, movies, music streaming, gaming, whole-home audio, scalable home theater |
| Control options | Touch display, WiiM Home App, voice control, and WiiM Bar Remote |
| Audio System | |
| Acoustic system | 8-driver acoustic system with 4 passive radiators |
| Front mid-woofers | 0.12 × 4.33 × 2.05 inches ( 3 x 110 × 52 mm) mid-woofers |
| Front tweeters | 0.12 × 2.05 × 2.05 inches (3 x 52 × 52 mm) tweeters |
| Top height drivers | 0.08 × 2.05 × 2.05 inches (2 x 52 × 52 mm) full-range drivers |
| Passive radiators | 0.16 × 4.53 × 1.97 inches (4 x 115 × 50 mm) passive radiators, front × 2 and rear × 2 |
| Max system power | 135 W |
| Native channel layout | 3.0.2 |
| Height effects | Top-firing height channels |
| Audio Formats & Home Theater | |
| Supported audio formats | LPCM, Dolby Atmos/TrueHD/DD , AC3, DTS, DTS:X |
| Dolby Atmos support | Yes, via supported content and compatible input setup |
| DTS:X support | Yes |
| HDMI home theater connection | HDMI eARC |
| Native configuration | 3.0.2 Dolby Atmos and DTS:X soundbar |
| Expandable configuration | Up to 5.1.2 with compatible WiiM surround and subwoofer devices |
| Surround expansion | Wireless surround support with compatible WiiM devices |
| Subwoofer expansion | Wireless subwoofer support with compatible WiiM devices |
| Smart Audio & EQ | |
| Room correction | RoomFit auto-correction |
| Dialogue enhancement | Clear Voice and AI Dialog Enhancement |
| Night listening | Night Mode |
| Sound modes | Movie Mode, Music Mode, Voice Enhance Mode, Night Mode |
| Preset EQ | 24 preset EQ settings |
| Graphic EQ | 10-band Graphic EQ |
| Parametric EQ | 10-band Parametric EQ, where supported in the WiiM Home App |
| Per-source EQ | Supported via WiiM Home App, where available |
| App customization | Sound modes, EQ, RoomFit, input settings, grouping, and device preferences |
| Display & On-Device Controls | |
| Display | Glass-covered 2.1-inch Hi-Res full-color round LCD touch screen |
| Display type | Round touch display |
| Display content | Album art, track information, time, EQ, Smart Presets, Recently Played, clock faces, dynamic wallpapers, and album art standby |
| Playback controls | Play, pause, skip, and like |
| Source controls | Source selection from the display |
| EQ controls | Quick EQ access on the device; deeper EQ control in the WiiM Home App |
| Smart Presets | One-tap access to favorite preset routines and content |
| Recently Played | Access to recently played playlists, stations, and shows |
| Personalization | Multiple clock faces, dynamic wallpapers, and album art standby |
| Proximity-lit capacitive buttons | Volume , Volume –, Play/Pause, Source Switch |
| Status LED | RGB W status LED |
| App, Voice & Remote Control | |
| App control | WiiM Home App |
| Voice control | Alexa and Google Assistant |
| Remote | WiiM Bar Remote |
| Remote controls | Playback, volume, source switching, sound modes, mute/unmute, standby, and voice control where available |
| On-device control | 2.1-inch round touch display and proximity-lit capacitive buttons |
| Setup control | WiiM Home App via WiFi or Ethernet |
| Ecosystem control | Manage streaming, grouping, EQ, presets, and compatible WiiM devices from the WiiM Home App |
| Inputs, Outputs & Connectivity | |
| HDMI | HDMI eARC |
| Optical | Optical In |
| Analog input | Line In |
| Ethernet | 10/100 Mbps Ethernet |
| USB | USB Host for storage |
| WiFi | WiFi 6E |
| WiFi bands | 2.4 GHz, 5 GHz, and 6 GHz |
| WiFi standard | 802.11 b/g/n/ax |
| Bluetooth | Bluetooth 5.4 |
| Bluetooth profiles | BLE, A2DP Rx/Tx, AVRCP, HID |
| LE Audio | Supported via software update |
| Bluetooth input | Stream from compatible phones, tablets, TVs, and laptops |
| Bluetooth output | Output to compatible Bluetooth speakers, headphones, or earphones, where supported |
| Wired network behavior | Ethernet available for a stable wired network connection |
| Streaming & Protocols | |
| Streaming app | WiiM Home App |
| In-app streaming | Stream 20 music services through the WiiM Home App |
| Casting and streaming protocols | Google Cast Audio / Chromecast Audio, Spotify Connect, TIDAL Connect, Qobuz Connect, Amazon Music Cast, DLNA/UPnP, Qplay 3.0, LMS, Roon |
| Example music services | Spotify, Amazon Music, YouTube Music, TIDAL, Qobuz, Deezer, TuneIn, SoundCloud, Pandora, iHeartRadio, vTuner, Napster, SoundMachine, KKBOX, Soundtrack Your Brand |
| AirPlay 2 | Not supported |
| Network playback | WiFi, Ethernet, DLNA/UPnP, and WiiM Home App |
| Direct app control | Supported with compatible services such as Spotify Connect, TIDAL Connect, Qobuz Connect, and Google Cast Audio |
| Multi-Room & WiiM Ecosystem | |
| WiiM multi-room audio | Group WiiM Bar with compatible WiiM devices for synchronized multi-room listening |
| Compatible WiiM ecosystem | Designed to integrate with WiiM Amp, WiiM Ultra, WiiM Pro, WiiM Mini, and WiiM Edition speakers for multi-room music grouping |
| Home theater expansion | Expand from 3.0.2 to up to 5.1.2 with compatible WiiM surround and subwoofer devices |
| Surround setup | Use compatible WiiM devices as wireless surround channels |
| Subwoofer setup | Add compatible WiiM subwoofer support for deeper bass |
| Other multi-room options | Alexa multi-room and Google Cast multi-room, where supported |
| Physical input multi-room | For Line In, Optical In, HDMI eARC, or Bluetooth as multi-room sources, use a WiiM-device group |
| USB Media Library | |
| USB function | USB Host for storage |
| Media library | Access a personal media library from connected USB storage |
| Media server | Can act as a media server for other WiiM and DLNA devices on the same network |
| Supported storage examples | USB drive or compatible external storage |
| Supported file systems | FAT32, NTFS, EXT4, where supported |
| Playback control | Browse and control USB media through the WiiM Home App |
| Physical | |
| Dimensions | 41.7 × 4.1 × 3.1 inches (1060 × 105 × 80 mm) |
| Height without foot | 3.1 inches (80 mm) |
| Weight | 11.02 lb / 5 kg |
| Placement | TV console or wall mount |
| Wall mounting | Wall brackets included |
| Display location | Front-facing 2.1-inch round touch display |
| On-device controls | Top-panel capacitive controls and front touch display |
| Status light | RGB W LED status indicator |
| POWER | |
| Power input | 100–240V AC |
| Frequency | 50/60 Hz |
| Max system power | 135 W |
| Power cable | Included |
| What's included | |
| What's Included | WiiM Bar, WiiM Bar Remote, User Guide, Power Cable, HDMI Cable, Optical Cable, Wall brackets × 2 with screws, |
